HDTV Supplys WolfPack™ 4K Sports Bar 24x32 HDMI Matrix Switch is a preconfigured integrated HDMI video and HDMI audio modular HDMI matrix router. The 36x36 chassis's back plane allows HDMI technologies to be converted and switched eliminating external converters and it allows any input to be routed to any output, or the same input to be routed to all outputs. The application is simple and easy to use because its based on your floor plan. The hardware/software combo can even automatically turn on all of your TV's to the desired TV channel and a time each morning of your choosing.
We think it's the best because it allows the iPad to become the complete remote control for all of your TVs and it also allows the user to see what is playing on the selected Cable boxes or DirecTV receivers in real time, prior to changing the channel. This gives you and your staff the ability to really focus on your customers rather than wasting time scrolling for games. The Sports Bar 24x32 HDMI Matrix Switcher manages HDMI input signals for the inputs and female HDMI outputs for HDMI cabling. By having 1-port slide in cards the matrix is very reliable as in the unlikely even there is a loss of signal you just replace the card with a spare you have purchased or order another from us. The complete matrix does not have to be sent to us for a repair.
This Sports Bar 24x32 HDMI Matrix Switcher supports long HDMI cables, maintains power reliability in the event of failure and offer the a great solution for any sports bar, night club or restaurant. Our 4K Sports Bar 24x32 HDMI Matrix Switcher also can support high-resolution HDMI sources routed to HDMI displays, monitors, projectors, or audio systems, in your sports bar, night club or restaurant.
This Sports Bar 24x32 HDMI Matrix Switch can do the following with an iPad:
- Send any of your 24 - Cable Boxes and/or DirecTV™ receivers to any of your 32 - TVs...in any combination
- Change any of the Cable Boxes and/or 24 - DirecTV™ TV channels
- Raise or lower any of the 32 - TVs volume
- Change the TVs being viewed in a Video Wall
- Turn ON all your 32 - TVs in the morning...even automatically
- Turn OFF all your 32 - TVs at night
- Put a single game onto multiple televisions with one tap of a finger
- Do all of the above, plus more, with the Free iOS App for an iPad.
Reasons that sets our WolfPack™ Sports Bar HDMI Modular Matrix Switchers apart from others:
- 4K/30 for the best picture
- 40 - Preset scenes that can be Saved and Recalled
- Optional Elan & 2-Way Control4 Drivers
- Optional HDBaseT HDMI to CAT6 extenders, not cheap H.264 with fuzzy compressed video
- Closed Caption (CC) Pass-through
- Additional control via an iPad App, Android App, Web Browser (WEB GUI), RS232 & Front Buttons
- 2-Power Supplys w/automatic switch-over if a problem occurs
- 2-Year WolfPackCare Advance Replace Warranty
- Free Lifetime Telephone, CHAT, TEXT and Email Tech Support
- Other in & out cards available like VGA, DVI, Fiber, SDI, composite and component and Audio
- Optional low cost Video wall Processors
Sports Bar 24x32 HDMI Matrix Switcher Features:
- Chassis size: 36 input and 36 outputs cards
- Input Cards Supported:
- 24 - 4K female HDMI single port cards = 24 - HDMI inputs
- Output Cards:
- 32 - 4K female HDMI single port cards = 32 - HDMI outputs
- Input HDMI cable distance: ~25 feet AWG24 HDMI 2.0 high speed cables
- Output HDMI cable distance: ~35 feet AWG24 HDMI 2.0 high speed cables
- Flexible card type design supporting 36 input cards and 36 output cards
- Hot Swappable with easy plug n play
- Dual RS232 serial control port, using serial commands
- Dual TCP/IP control via Ethernet
- 40-Global presets to save and recall the function
- Advanced EDID management for rapid integration of sources and displays
- Front-panel push buttons for local switching
- IP controlled via built-in web server and LAN (WEB GUI)
- RS-232 Serial interface for remote control
- Supports seamless switching, no black/ blue/ split screen while switching
- Supports resolution exchanges with several resolutions can be chosen and used
- Control via Web / RS232 and Front Buttons control (no remote control)
- Rack-mountable
Why not buy this Sports Bar 24x32 HDMI Matrix Switcher today?
These HDMI Matrix Switchers have an option to add a 1080p 3U Rack Mount 7" inch Dual Color Display (shown) for you to select & see screens of what is happening in your matrix system located in other rooms. It requires the dedicated use of 2-of the HDMI outputs to wire to the 2-HDMI inputs of the dual display. Those 2-Matrix HDMI outputs cannot be used for anything else so count the number of outputs you need and add two (2) more to see if this matrix fulfills your needs. Also, the sources feeding the displays must be set at 1080p.
Supports EDID Management: Ensure that even the most difficult display can receive audio and video with eight programmable memory presets loadable to any source connected to the matrix.
Modular HDMI Matrix Switcher Specs:
- Modular Configuration: 36 and 36 outputs
- Input cable distance: ~25 feet AWG22 HDMI 1.4 high speed cable
- Output cable distance: ~35 feet AWG22 HDMI 1.4 high speed cable
- Supported Input & Outputs Signals:
- HDMI and Display Port: up to 4K at 30 Hz
- Control: TCP/IP, RS232 and front buttons
- 2-Power Supplies: 100 to 240VAC, 50-60Hz
- Power Consumption: 50W 70W
- Operating Temperature: -10℃ to 50℃
- Storage Temperature: -25℃ to 55℃
Why not buy this Sports Bar 24x32 HDMI Matrix Switcher today?
WolfPack Modular HDMI Matrix Switcher Comparison Spreadsheet
DO NOT USE EZ45 CAT6 CONNECTORS WITH HDBaseT PRODUCTS
EDID Operation for the HDBaseT Transmitter
EDID Learning Instruction for the Cards
SDI Card Specs
RS232 Commands in HEX and ASCII format
Why not buy this Sports Bar 24x32 HDMI Matrix Switcher today?
Reasons To Buy an HDTV Supply WolfPack Product
Why not buy this Sports Bar 24x32 HDMI Matrix Switcher today?
Free Android and iOS App: The IOS App for this WolfPack card cage matrix is in the Apple Application Store and when you SEARCH the key words "MCS" or "Matrix Control System" you can download and install it to your iPad or iPhone. Also from your iPad or iPhone click the following link...MCS-matrix control system to install it directly.
For the Android App click the following link and download it. Go to Android App for control of this HDMI matrix switch.
Here is the RS232 User Manual if you want to write your own drivers.
Also, CLICK HERE for our DirecTV™ & HDMI Matrix Control Software for Bars & Restaurants
Why not buy this Sports Bar 24x32 HDMI Matrix Switcher today?
Control
Along with the bundled hardware and software combo the matrix also comes with its default control methods. These control options are not part of the sophisticated software that the hardware is bundled but can be used. Please call us for more explanation of how they can be used to coexist with the WolfPack software.When one is designing an HDMI Matrix Switch the most important initial specification is the number of inputs and outputs you will need in your facility. The next, and often forgotten, is how the user wants to control those inputs and outputs. HDTV Supply has your back when you're buying one of our WolfPack Family of Modular Matrix Switchers as we have dozens of way to control the inputs and outputs and are shown at Controlling WolfPack Modular Matrix Systems, as well as below:
- iPad App (iOS)
- iPhone App (iOS)
- iPod App (iOS)
- Android Tablet App
- Android Phone App
- Samsung Galaxy Tablet App
- Samsung Galaxy Phone App
- Web GUI from any browser
- Dual RS232 ports
- Dual LAN (TCPIP) ports
- Front panel push-buttons
- Color Touchscreens
- Our DTV Sports Bar Control System
- One-Way Control4 Drivers
- 2-Way Control4 Drivers
- URC Drivers
- Elan Drivers
- RTI Drivers
- ...and more.
For an up-to-date listing of all the methods to control our WolfPack Matrix Switchers go to Ways to Control Our WolfPack Family Of Modular Matrix Systems.
Why not buy this Sports Bar 24x32 HDMI Matrix Switcher today?
These modular HDMI matrix switchers can usually be integrated with many third party control systems using the RS232 port on the back of the matrix.
For experienced AV hardware and software professionals who want to write their own drivers for 3rd party control systems from:
- AMX™
- Control4™
- Creston™
- RTI™
- DTVGameControl™
- Elan g!™
- Media Switcher™
- OnControls™
- Savant™
- SimpleControl™
- SwitchItUp™
- SAVI Control™
- URC Control™
...and we have created a simple and very easy to use RS232 script to write your own drivers.
EXAMPLE: If you want to switch input 8 to output 1, 8, 16, the RS232 command would be 8x1&8&16. and notice the command has a period (.) at the end of the string. The matrix even replies "OK" when the right command is received and shows "ERR when receiving a wrong command. Here is the RS232 User Manual if you want to write your own drivers.
How to use the info:
END USER: If you are an end user and want to have a whole-house control system from any of the above 3rd party control houses but your budget can't support the price you were quoted, do the following:
- Call us for a quote
- Once you get our quote call a 3rd party control reseller or installer in your area and tell them "Here is the hardware I want to use, please give me a quote on writing the software and installing all of the hardware at my location." You usually can save $1,000s on larger systems.
CAVEAT: We are not certified by any of the above 3rd party control systems companies nor have the necessary hardware to verify, troubleshoot and support the 3rd party writing of the code. We do warranty, though, that the RS232 script in the above RS232 User's Manual has and will work to control the matrix directly.
Also, CLICK HERE for our DirecTV™ & HDMI Matrix Control Software for Bars & Restaurants
Why not buy this Sports Bar 24x32 HDMI Matrix Switcher today?
A: You can choose either to open or close the HDCP on the output card. A receiver that cannot support HDCP can also display the sources with HDCP.
- Mix-n-Match combinations:
- Non-HDCP source to a HDCP compliant TV
- HDCP source to a non-HDCP compliant TV
A: Our testing procedure is:
- Assembling: Production line self-testing (Basic Functions)
- Initial Testing: Includes every card, control software and front panel front buttons
- 24 Hours Aging: Gao Sheng Standard Aging Room
- Final testing: All Functions
- QC final Inspection: Sticker, serial number, etc
- Packing: Pack and ship
A: For the 2 power supply system on the card cage matrix, it's a redundant system. We can have two power supply system on at the same time (if one's down, it can hop to another, it guarantees the matrix won't shut down). It also can operate with just one power supply on and the other one is for back-up
Q: What are the dimensions of the chassis?
A: They are:
9x9: 2U - 482x390x88mm(L/W/H) - 18.97x15.35x3.46 inches
18x18: 4U - 482x390x178mm(L/W/H) - 18.97x15.35x7.01 inches
36x36: 8U - 482x390x55mm(L/W/H) - 18.97x15.35x13.98 inches
80x80: 16U - 482x390x711mm(L/W/H) - 18.97x15.35x27.99 inches
160x160: 31.5U - 482x465x1400mm (L/W/H) - 18.97x18.31x55.12 inches
Q: Do you have any tips in the unlikely event the unit fails?
A: Turn it OFF and then disconnect the matrix from the AC power and all cables. Pull out each board from the rear and push back in. Plug all cables back in and turn it on.
Why not buy this Sports Bar 24x32 HDMI Matrix Switcher today?
HDTV Supply's WolfPack Family of Matrix Switchers can be created however you wish. Just SCROLL DOWN and fill out the below and press SUBMIT and we will send you a quotation based upon your needs within an hour.
If it doesn't meet your needs just call us right now at 833-WOLFPACK or 833-965-3722 or email us at support@hdtvsupply.com
