This Zenty ZT-333 IP400 4K 60Hz 4:4:4 AV Over IP System Decoder provide a flexible, powerful, and scalable solution at resolutions up to 3840 x 2160@60hz 4:4:4. They allow 4k UHD media to be switched and distributed over standard gigabit Ethernet networks, providing complete end-to-end streaming systems. Audio, video together with IR, and USB signals can be routed separately or as a whole throughout the matrix system. Encoders can be used with decoders to function a video wall up to dimensions of 16 x 16. Both of them have the capacity to handle and output up to 7.1 audio channel, allowing you to enjoy the finest sounds.
HDCP 2.2/2.3 specifications are employed. A local area network is covered with a range up to 330ft (100m) over a single Cat 5e cable or above. Standard features like, bi-directional serial, bi-directional IR, and independent analog audio input/output are included. The codecs allow roaming/USB extension to take place to control keyboard and mouse. Flexible control options are offered -- Windows PC configurator (Z-Net Configuration Tool), Z-Net on iPad and IP controller (ZT-IP100C). They are the perfect solution for any low latency and signal routing applications. Common applications include home, classrooms, conference rooms, and broadcasts.
Zenty ZT-333 IP400 4K 60Hz 4:4:4 AV Over IP System Decoder Features:
- Supports up to 4K@60Hz 4:4:4 resolution. IP400 series support HDR10 and Dolby Vision only if the device‘s HDMI Timing Hybrid is set to “Pass-through“ mode (default setting).
- Supports CEC one-touch-play and standby commands to power on and off the displays, as well as CEC Frame. Features video wall up to dimensions of 16 x 16.
- Supports Multi-Channel audio up to PCM 7.1, Dolby Atmos, DTS HD Master and DTS:X.
- Allows AV, USB, IR, RS232 and power signals to be delivered up to 328ft/100m over a single Cat 5e cable or above.
- Units can be connected via 1G Optical port or 1G Base-T (Gigabit Ethernet) port. When using with 1G Optical port, power supply is needed for both encoder and decoder.
