This Zenty ZT-114 4x4 4K 60Hz HDMI Matrix with Audio Out is a professional UHD 4K@60Hz 4:4:4 HDR HDMI video distribution matrix switcher. With 18Gbps HDMI 2.0 support, the ZT-MT44A 4×4 HDMI Matrix allows up to four UHD 4K sources to be independently routed to four UHD displays. All four outputs support audio de-embedding via coaxial S/PDIF or analog phoenix connectors. Pair the audio de-embedding function with the ZT-MT44A's EDID management tool (built in EDID + EDID copy) and you have an incredibly versatile and flexible HDMI routing system suitable for a number of applications.
Zenty ZT-114 4x4 4K 60Hz HDMI Matrix with Audio Out Features:
- 4 Inputs to 4 Outputs - The 4×4 HDMI Matrix routes up to four 4K HDR HDMI sources to four 4K HDR display devices. Allow all outputs to mirror the same signal or independently route unique input signals to each display for a fully customized HDMI routing matrix
- HDR & Dolby Vision - HDMI 2.0 and HDCP 1.4 / 2.2 Compliant. Users can enjoy all of the latest formats and standards with this 4×4 HDMI 2.0 Matrix including 4K, HDR, HDR10, Dolby Vision, Dolby Atmos, DTS-X
- De-Embed analog or digital audio signals and route audio to 3rd party devices like soundbars, amplifiers or AV receivers via coaxial S/PDIF or analog phoenix connectors
- Manage HDMI signal routing, customized routing presets and EDID for ultimate flexibility and compatibility with various applications
Why not buy this Zenty ZT-114 4x4 4K 60Hz HDMI Matrix with Audio Out from HDTV Supply today?
Zenty ZT-114 4x4 4K 60Hz HDMI Matrix with Audio Out Specification:
- Audio
- Audio From HDMI Output: Up to LPCM 7.1 of 24-bit / 192KHz, Dolby Atmos, Dolby TrueHD, and Dolby Legacy Formats DTS:X, DTS-HD Master Audio, DTS 96KHz / 24 bits, and DTS Legacy Formats
- Digital Output Format: PCM 2.0, Dolby True HD, DTS-HD Master Audio, LPCM 7.1
- Analog De-Embed: Up to LPCM 2.0 of 24-bit / 96KHz (Input CODEC must be LPCM/PCM)
- Output
- 4 x S/PDIF (Coaxial)
- 4 x 3-pin phoenix
- Video
- Chroma Sampling: 4:4:4, 4:2:2, 4:2:0
- Color Depth: 8, 10, 12 bits per color
- Color Format: RGB and YCbCr digital video
- Colors: 1 Billion (10-bit processing)
- EDID: EDID Management and EDID Copy
- Frame Rate: 24, 25, 30, 50, 60, 120, 144, 240 FPS
- HDR: HDR-10, Dolby Vision, HLG
- Maximum Data Rate: 18 Gbps (6 Gbps per color)
- Maximum Pixel Clock: 600 MHz
- Resolution: Up to 4K @ 60Hz
- Routing: 4 x 4
- Input: 4 x HDMI Type A
- Output: 4 x HDMI Type A
- Specification: DVI 1.0, HDMI 1.4, HDMI 2.0, HDCP 1.4, HDCP 2.2
- Communications
- Control Program: Web
- USB Port: 1 x USB Micro B
- IR Extender: For IR Remote Controller
- IR Connector: 1 x 3.5mm jack
- IR Carrier Frequency: 38KHz
- Serial Port: RS-232
- Serial Connector: 1 x 3-pin phoenix
- Serial Baud Rate: 115200
- Serial Data Bit: 8 bits
- Serial Stop Bit: 1 bit
- Serial Parity: None
- Serial Pin Configuration: TX-GND-RX
- Ethernet Port: 1 x RJ45
- Ethernet IP Address: 192.168.1.168
- Ethernet DHCP: Off
- Ethernet Gateway: 192.168.1.1
- Ethernet Subnet Mask: 255.255.255.0
- General
- Enclosure Type: Metal
- Operating Humidity: 5% RH - 90% RH (non-condensing)
- Operating Temperature: 32°F - 104°F
- Power Supply Input: AC 100V - 240V, 50Hz - 60Hz
- Power Supply Output:DC 12V/2A, 24W
- Power Consumption: 14W
- Rack Mount: No
- Regulatory Compliance: CE, PSE, RoHs, UL
