Zenty ZT-108 4K 60Hz 4:4:4 HDBaseT HDMI over Ethernet Extender 394ft

Zenty

Zenty ZT-108 4K 60Hz 4:4:4 HDBaseT HDMI over Ethernet Extender 394ft
$410.00

25% Discount. Apply Code 25percentOff at Checkout!

Part Number:
ZT-108
Condition:
New
1:
Up To 4K 60HZ
2:
Transmit 1080p up to 492 ft
3:
HDMIOutput
4:
RS232
5:
Free USA Shipping
6:
International Shipping w/Wire Transfer
7:
Hassle-free Warranty
8:
5-Year Zenty Warranty
9:
Free Returns within 60 Days
10:
Lifetime Technical Support
11:
Save 5% with Wire Transfer or Check
Make a Fair Offer
Ask an Expert

This Zenty ZT-108 4K 60Hz 4:4:4 HDBaseT HDMI over Ethernet Extender 394ft is a professional UHD 4K@60Hz 4:4:4 HDR HDMI over Ethernet extender solution. Users can transmit a 4K@60Hz signal up to 120M/394Ft. and a 1080P@60Hz signal up to 150M/492Ft. over a single Cat5e/Cat6 Ethernet cable. The ZT-EX1504K transmitter features a local HDMI output port for splitting your source signal locally and extending an output to a remote display. Utilize the built-in PoC (Power over Cable) function and power both your transmitter and receiver from only one power adapter.

Installation is simple, quick, and easy. The ZT-EX1504K will pass your display's EDID information to your connected source device so that any signal compatibility issues will be resolved before they even begin. Flexible and appropriate for any application, the ZT-EX1504K supports the latest audio and video standard including HDR, HDR10, Dolby Vision, Dolby Digital+, DTS-HD Master & Dolby TrueHD.

Zenty ZT-108 4K 60Hz 4:4:4 HDBaseT HDMI over Ethernet Extender 394ft Features:

  • Up To 4K 60HZ 4:4:4 HDR Resolution – Transmit 4K@60Hz 4:4:4 HDR HDMI Signals up to 394 ft. (120m) via HDBaseT. Transmit 1080p up to 492 ft. (150m) over a single Cat5e/6 cable
  • Local Transmitter Loop Out – Connect a display to the transmitter’s HDMI output port to a local display via HDMI to view the signal being sent to the receiver
  • Bi-Directional IR & CEC, RS232 Pass-Through – Control your source from your display/receiver side, or vice-versa via Bi-Directional IR. Pass RS-232 or CEC commands from source to display or from display to source via Bi-Directional CEC & Bi-Directional RS-232 pass-thru
  • Power over Cable & EDID Pass-Through – Take advantage of the Power over Cable feature and power both your transmitter and receiver from only one power adapter. Power adapter can be placed on either the transmitter or receiver side for maximum convenience. The ZT-EX1504K passes your display’s EDID information to your source device so that you can avoid signal compatibility issues all together
  • Dolby Vision & Dolby Digital+ Supported – Enjoy the latest digital content the way it was intended. ZT-EX1504K supports 4K 60Hz 4:4:4 signals and HDR / HDR-10 / Dolby Vision metadata. Supported surround sound formats include Dolby TrueHD, DTS HD Master and Dolby Digital+

Why not buy this Zenty ZT-108 4K 60Hz 4:4:4 HDBaseT HDMI over Ethernet Extender 394ft from HDTV Supply today?

Zenty ZT-108 4K 60Hz 4:4:4 HDBaseT HDMI over Ethernet Extender 394ft Specification:

  • Audio
    • Audio From HDMI Output: Up to LPCM 7.1 of 24-bit / 192KHz, Dolby Atmos, Dolby TrueHD, and Dolby Legacy Formats DTS:X, DTS-HD Master Audio, DTS 96KHz / 24 bits, and DTS Legacy Formats
    • Digital Output Format: LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD, Dolby Digital Plus (DD+), DTS-ES, DTS HD Master, DTS HD-HRA, DTS-X
    • Analog De-Embed: Up to LPCM 2.0 of 24-bit / 96KHz (Input CODEC must be LPCM/PCM)
    • Output: 2 x 3-pin phoenix
  • Video
    • Chroma Sampling: 4:4:4 (60Hz)
    • Color Depth: 8, 10, 12 bits per color
    • Color Format: RGB and YCbCr digital video
    • Colors: 1 Billion (10-bit processing)
    • EDID: EDID Management and EDID Copy
    • HDR: HDR-10, Dolby Vision, HLG
    • Maximum Data Rate: 18 Gbps (6 Gbps per color)
    • Resolution: Up to 4K @ 60Hz
    • Input
      • Transmitter:
      • 1 x HDMI Type A
      • 1 x IR
      • 1 x RS-232
      • Receiver:
      • 1 x IR
      • 1 x RJ45 (HDBaseT)
    • Output
      • Transmitter:
      • 1 x HDMI Type A Loop-out (19-pin)
      • 1 x IR Out (3.5mm Stereo Mini-Jack)
      • Receiver:
      • 1 x HDMI Type A Out (19-pin)
      • 1 x IR Out (3.5mm Stereo Mini-Jack)
      • 1 x Audio Out (3.5mm Stereo Mini-Jack)
      • 1 x RS-232 Out (phoenix)
    • Specification: HDMI 2.0, HDCP 1.4, HDCP 2.2
  • Communications
      • IR Extender: For IR Remote Controller
      • IR Connector: 1 x 3.5mm jack
      • IR Carrier Frequency: 38KHz - 56KHz
      • Serial Port: RS-232
      • Serial Connector: 1 x 3-pin phoenix
      • Serial Baud Rate: 115200
      • Serial Data Bit: 8 bits
      • Serial Stop Bit: 1 bit
      • Serial Parity: None
      • Serial Pin Configuration: TX-GND-RX
  • General
    • Enclosure Type: Metal
    • Operating Humidity: 20% RH - 90% RH (non-condensing): Operating Temperature
      32°F - 104°F
    • Power Supply Input: AC 100V - 240V, 50Hz - 60Hz
    • Power Supply Output: DC 24V/1A
    • Power Consumption: 9.36W
    • Regulatory Compliance: CE, PSE, RoHs, UL

Why not buy this Zenty ZT-108 4K 60Hz 4:4:4 HDBaseT HDMI over Ethernet Extender 394ft from HDTV Supply today?

Zenty ZT-108 User Manual
