This Thor Broadcast H-HDMI-KVM-Tx/Rx KVM + HDMI + Analog Audio + USB Over CAT5e/6 LAN Extender 200 Meters transmits HDMI audio and video signals up to 200 meters via CAT5e/6 cable. The Tx/Rx supports the TCP/IP network protocol, enabling transmission from one transmitter to multiple receivers through Ethernet switches.
It transmits HDMI signals and also features a local loop-out for live viewing. Additionally, it includes IR infrared return transmission, independent audio transmission, and remote control IR of the signal source.
The device also incorporates EDID data and built-in audio, enhancing the HDMI extender's compatibility over Ethernet.
It offers excellent transmission distance for copper with HD 1080p60, facilitating low-cost, easy installation using existing CAT LAN lines in any application.
The system is widely used in information systems, security monitoring, video conferencing systems, HD teaching systems, LCD splicing, LED fusion, and more.
Thor Broadcast H-HDMI-KVM-Tx/Rx KVM + HDMI + Analog Audio + USB Over CAT5e/6 LAN Extender 200 Meters Features:
- HDMI video maximum resolution 1920*1080P@60Hz with downward compatibility
- Integrated HDCP compliance engine to receive protected audio and video content
- EDID transparent transmission mode, automatically matching the signal source and display
- Transmitter has local loopout for HDMI
- 24bit-embedded digital audio
- Independent analog of 3.5mm audio
- Audio embedding/unembedding function
- KVM function (keyboard and mouse)
- Reverse IR infrared
- Point to point, point to multipoint, multipoint to multipoint transmission through ethernet switches (up to 255 points)
- Transmission distance up to 200 meters through CAT5e/6 cable
- Built-in ESD electrostatic protection circuit, simple to install, plug and play
- The equipment has a differentiated transmitter (signal source), and receiver (display end). Ships as a transmitter and receiver set.
Why not buy this Thor Broadcast H-HDMI-KVM-Tx/Rx KVM + HDMI + Analog Audio + USB Over CAT5e/6 LAN Extender 200 Meters from HDTV Supply today?
Thor Broadcast H-HDMI-KVM-Tx/Rx KVM + HDMI + Analog Audio + USB Over CAT5e/6 LAN Extender 200 Meters Specification:
|
Video index |
|
|
Video version |
HDMI 1.3 (full-digital) |
|
HDCP protocol |
1.2 |
|
Maximum pixel clock |
148.5MHZ |
|
Resolution |
720 (1440) x 480i @ 59.94/60Hz 720 (1440) x 576i @ 50Hz 720 x 480p @ 59.94/60Hz 720 x 576p @ 50Hz 1280 x 720p @ 59.94/60Hz 1280 x 720p @ 50Hz 1920 x 1080i @ 59.94/60Hz 1920 x 1080i @ 50Hz 1920 x 1080p @ 23.98/24Hz 1920 x 1080p @ 59.94/60Hz 1920 x 1080p @ 50Hz |
|
Effective cable length |
Less than 10m |
|
Physical interface |
The HDMI-A interface |
|
KVM(USB) index |
|
|
Version |
1.1 |
|
Tx physical interface |
USB female type A |
|
Rx physical interface |
USB female type A |
|
Audio index |
|
|
Sampling frequency |
32k, 44.1k, 48k, 64k, 88.2k, 96k, 176.4k, 192kHz |
|
Sampling depth |
24bit |
|
Dynamic bandwidth |
96db |
|
Total harmonic distortion(THD) |
-88db |
|
Signal to noise ratio(SNR) |
96db |
|
Audio input / output impedance |
600Ω |
|
Signal level |
VPP 3.3V |
|
Physical interface |
3.5mm stereo audio socket |
|
Signal type |
Analog stereo channel |
|
IR index |
|
|
Infrared interface |
Standard 3.5mm interface |
|
Infrared frequency |
Standard with 20-60KHz |
|
Signal type |
Digital signal |
|
Infrared transmission direction |
Reverse transmission |
|
Other indexes |
|
|
Operating temperature |
-20°C ~70°C |
|
Storage temperature |
-40°C ~85°C |
|
Product size |
104*104*28mm |
|
Product net weight (Pair) |
0.35/kg |
|
Product weight (including outer packaging) |
0.6/kg |
|
Product outer packaging dimensions |
275*220*55mm |
|
Power supply |
5V 1A |
|
Power dissipation |
≤2.5W |
