This SurgeX SX-DS-156 Defender Series MultiPak, 120V/15A, 1 NEMA 5-15P, 6 NEMA 5-15R is the premier power protection choice to safeguard multi panel digital displays and projectors from the dangers associated with electrical transients. Its Multi-Stage technology is superior to the single-stage MOV circuitry found in conventional surge protectors and is instrumental in reducing downtime. This technology ensures the highest level of protection from damaging surges, spikes, over/under voltage, EMI/RFI noise, and wiring faults to increase the reliability of connected equipment and its uptime. The MultiPak is completely non-sacrificial and never requires reset, even after repeated disturbances.
The compact design easily integrates with wall/ceiling mounting systems to conceal it from view. Available in four and six receptacle configurations, the MultiPak is the clear choice to protect multi panel displays.
SurgeX SX-DS-156 Defender Series MultiPak, 120V/15A, 1 NEMA 5-15P, 6 NEMA 5-15R Features:
- Protects equipment from power disturbances that can cause downtime, disruption, shutdown, and loss of income
- Superior technology to conventional single-stage MOV circuitry
- Improves audio and video performance
- Increases the reliability of connected equipment
- Completely non-sacrificial and never requires rest
- Compact design easily integrates with wall/ceiling mounting systems
- SXDS156 Defender Series MultiPak, 120V/15A, 1 NEMA 5-15P, 6 NEMA 5-15R
- Superior technology to conventional single-stage MOV circuitry
- Protects equipment from power disturbances that can cause downtime, disruption, shutdown, and loss of income
- Improves audio and video performance
- Increases the reliability of connected equipment
- Completely non-sacrificial and never requires rest
- Compact design easily integrates with wall/ceiling mounting systems
Why not buy this SurgeX SX-DS-156 Defender Series MultiPak, 120V/15A, 1 NEMA 5-15P, 6 NEMA 5-15R today?
SurgeX SX-DS-156 Defender Series MultiPak, 120V/15A, 1 NEMA 5-15P, 6 NEMA 5-15R Specifications:
- Load Rating: 15 Amps @ 120 Volts
- Voltage Protection Rating (VPR): 330V All Modes
- EMI/RFI Filter, Normal Mode (50-ohm load): > 30 dB 80kHz - 50MHz
- EMI/RFI Filter, Common Mode (50-ohm load): > 30 dB 70kHz - 50MHz
- Overvoltage Shutdown: Adjustable from 135V to 160V. Restores at 130V
- Undervoltage Shutdown: Adjustable from 80V to 95 V, or Disabled. Restores at 105V
- Dimensions (W x D x H): 11.212" x 7.272" x 1.79"
- Weight: 5.0 lbs.
- Temperature Range: 5° to 35° C
- Humidity Range: 5% to 95% R.H., non-condensing
- Agency Listings: ETL and cETL Certified to UL 1449 (pending)
- FCC: Part 15 Class B
Why not buy this SurgeX SX-DS-156 Defender Series MultiPak, 120V/15A, 1 NEMA 5-15P, 6 NEMA 5-15R today?
