This Osprey 95-00474 260eSS 1x Composite or 1x S-Video or 1x Component, 1x Unbalanced or Balanced Stereo Audio is a single-channel analog capture card offering Composite BNC, Component 3-BNC, and S-Video mini-DIN selectable inputs, along with balanced XLR or unbalanced RCA stereo audio, all via a breakout cable. The S-Video input comes on BNC connectors and is converted via an included BNC to mini-DIN adapter. Two or more cards can be deployed in a single PC chassis for maximum versatility.
This 260e card comes with Osprey's SimulStream driver enhancement software, which allows each input to produce multiple parallel output streams with completely independent settings for color space, cropping, scaling, closed caption, and overlays, allowing for simultaneous delivery to multiple applications.
Osprey 95-00474 260eSS 1x Composite or 1x S-Video or 1x Component, 1x Unbalanced or Balanced Stereo Audio Features:
- Driver Support
- Microsoft DirectShow drivers are available for compatibility with most software
- Open source Linux V4L drivers available
- Microsoft Windows lets you create custom applications
- Driver Based Pre-Processing (Windows DirectShow Only)
- Closed-caption extraction/rendering
- Logo/bitmap overlay
- Scaling, cropping, de-interlacing, and inverse telecine
Why not buy this Osprey 95-00474 260eSS 1x Composite or 1x S-Video or 1x Component, 1x Unbalanced or Balanced Stereo Audio today?
Osprey 95-00474 260eSS 1x Composite or 1x S-Video or 1x Component, 1x Unbalanced or Balanced Stereo Audio Specifications:
- Format: 1 x PCIe, Slots: x1, x4, x8, or x16, PCIe 1.1
- Breakout Cable Connector: 15-pin connector (breakout cable included)
- Video Input: 1 x Composite on BNC, 1 x Component on 3 BNCs, 1 x Y/C on 2 BNCs (BNC to mini-DIN adapter)
- Video Modes: NTSC/PAL, 720 x 480 29.97, 30/i (NTSC), 852 x 480, 29.97, 30/i (NTSC Wide Screen), 720 x 576 25/i (PAL), Wide Screen Signaling (WSS)
- Audio Input: 1 x Balanced stereo via 2 XLR connectors, 1 x Unbalanced stereo via 2 RCA connectors
- Audio Output: Unbalanced stereo line (3.5 mm)
- Power Consumption: 3.58 W
- Operating Temperature: 32 to 104°F (0 to 40°C)
- Storage Temperature: -40 to 167°F (-40 to 75°C)
- Operating Relative Humidity: 5 to 80% (non-condensing)
- Storage Relative Humidity: 95% RH (non-condensing); gradient 30% per hour
- Operating Altitude: 0 to 10,000 ft (0 to 3,048 m)
- Storage Altitude: 0 to 50,000 ft (0 to 15,240 m)
- Dimensions: L x H: 5 x 2.7" (12.7 x 6.7 cm), Low profile/half length
- Weight: 2.3 oz (67 g)
