Kramer VM-4DT 1:4 4K60 4:2:0 Long-Reach HDBaseT DA is a high-quality, long-reach 4K@60Hz (4:2:0) HDBaseT extender distributor that takes one long-reach HDBaseT input, equalizes and reclocks the signal and distributes it to four identical HDBaseT outputs. VM-4DT distributes native HDBaseT signals with up to 4K video resolution, along with their re-extension over HDBaseT.
Kramer VM-4DT 1:4 4K60 4:2:0 Long-Reach HDBaseT DA Features:
- High Performance Distribution - Distributes one native, long-reach HDBaseT signal to three outputs with up to 4K video resolution, along with their re-extension over HDBaseT.
- Dual-side Extension - Extends a 4K@60Hz (4:2:0) 24bpp (maximum) video signal to a distance of up to 40m (130ft) long-reach, and even further for lower video resolutions, when deployed mid-way between an AV source and multiple remote acceptors using CAT copper cable.
- Standard Compatibility - Connects to any HDBaseT compliant extension product on the market.
- HDMI Signal Transmission - HDMI 2.0 and HDCP 1.4 compliant signal, supporting deep color, x.v.Color, lip sync, 7.1 PCM, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D. EDID and CEC (OUT 1 only) signals are passed through from the source to the display.
- I-EDIDPro Kramer Intelligent EDID Processing - An intelligent EDID handling, processing and pass-through algorithm that ensures Plug and Play operation for HDMI source and display systems.
- LED Indicators - Status indicators for HDBaseT input/output connected signals and power for ease of maintenance and troubleshooting.
- Easy Installation - Twisted-pair cables for HDBaseT signals wiring. Standard half-width 19" rack (1U) fan-less enclosure for side-by-side mounting of 2 units in a 1U rack space with included rack mounting-ears.
Why not buy this Kramer VM-4DT 1:4 4K60 4:2:0 Long-Reach HDBaseT DA today?
Kramer VM-4DT 1:4 4K60 4:2:0 Long-Reach HDBaseT DA Specifications:
- Input: 1 HDBT on an RJ-45 female connector
- Outputs: 4 HDBT on RJ-45 female connectors
- Max. Data Rate: 10.2Gbps (3.4Gbps per graphic channel)
- Range Extension (Input or Output Each Side)
- Up to 40m (130ft) at 4K@60Hz (4:2:0),
- Up to 70m (230ft) at full HD (1080p @60Hz 36bpp),
- Note: When using Kramer HDBaseT cables
- Max. Video Resolution: 4K@60Hz (4:2:0) 24bpp
- Compliance: Supports HDMI 2.0, HDCP 1.4 and HDBaseT 1.0
- Controls
- EDID setup button, indicator LEDS: OUTPUTS 1-4
- LINK 1-4
- active input, power on
- Operating Temperature: 0˚ to +40˚C (32˚ to 104˚F)
- Storage Temperature: -40˚ to +70˚C (-40˚ to 158˚F)
- Humidity: 10% to 90%, RHL non-condensing
- Power Consumption
- Power source: 5.2V DC, 4A
- power consumption: 5V DC, 3.5A
- Enclosure: Desktop size, Aluminum type
- Cooling: Fan ventilation
- Product Dimensions: 21.5cm x 16.3cm x 4.4cm (8.4" x 6.4" x 7.2") W, D, H
- Product Weight: 0.53kg (1.67lbs) approx
- Shipping Dimensions: 31.5cm x 21.2cm x 7.2cm (12.4" x 8.4" x 2.8") W, D, H
- Shipping Weight: 1.29kg (2.83lbs) approx
- Included Accessories: Power supply
- Product Dimension: 21.46cm x 16.30cm x 4.36cm (8.45" x 6.42" x 1.72" ) W, D, H
- Product Weight: 1.0kg (2.2lbs) approx.
- Shipping Dimension: 35.10cm x 21.20cm x 7.20cm (13.82" x 8.35" x 2.83" ) W, D, H
- Shipping Weight: 1.5kg (3.3lbs) approx.
