Kramer 6241HDXL 4x1 3G HD–SDI Switcher
This Kramer 6241HDXL 4x1 3G HD–SDI Switcher is a high-performance switcher for 3G HD-SDI video signals. It takes any one of four 3G HD-SDI inputs, provides reclocking and equalization, and outputs the signal to one 3G HD-SDI output.
Kramer 6241HDXL 4x1 3G HD–SDI Switcher Features:
- Max. Data Rate – 3Gbps.
- HDTV Compatible.
- Multi–Standard Operation – SDI (SMPTE 259M and SMPTE 344M), HD–SDI (SMPTE 292M) and 3G HD–SDI (SMPTE 424M).
- Kramer Equalization & re–Klocking™ Technology – Rebuilds the digital signal to travel longer distances.
Kramer 6241HDXL 4x1 3G HD–SDI Switcher Applications:
- Video broadcast studios for signal routing.
- Non-linear editing suites.
- Video production studios.
- Boardrooms and classrooms.
Why not buy this Kramer 6241HDXL 4x1 3G HD–SDI Switcher today?
Kramer 6241HDXL 4x1 3G HD–SDI Switcher Specifications:
- INPUTS: 4 SMPTE 259M/344M serial digital video inputs (75Ω) on BNC connectors
- OUTPUTS: 1 SMPTE 259M/344M serial digital video output (75Ω) on BNC connectors
- MAX. DATA RATE: 2.97Gbps
- MAX. OUTPUT LEVEL: 800mVpp/75Ω
- EQUALIZATION: Automatic equalization for losses on 75Ω coaxial cable
- POWER CONSUMPTION: 5V DC, 410mA
- INCLUDED ACCESSORIES: Power supply, mounting bracket
- OPTIONS: RK–3T 19" rack adapter
- PRODUCT DIMENSION: 12.00cm x 7.15cm x 2.44cm (4.72" x 2.81" x 0.96" ) W, D, H
- PRODUCT WEIGHT: 0.2kg (0.5lbs) approx
- SHIPPING DIMENSION: 23.20cm x 12.00cm x 8.90cm (9.13" x 4.72" x 3.50" ) W, D, H
- SHIPPING WEIGHT: 0.5kg (1.2lbs) approx
