KanexPro SW-2X14KUSBC 2-Input Collaboration System for Huddle Rooms

KanexPro

Call for availability

Part Number:
SW-2X14KUSBC
UPC:
813982021969
Availability:
Usually ships the same business day
1:
2x1 USB-C & HDMI Auto Switcher
2:
Video Conferencing Support
3:
Intelligent Automatic switching
4:
Built-in EDID management
5:
Free Shipping & Free 3-Year KanexPro Warranty
KanexPro SW-2X14KUSBC 2-Input Collaboration System for Huddle Rooms

KanexPro SW-2X14KUSBC 2-Input Collaboration System for Huddle Rooms switcher addresses the everincreasing need to connect USB-C based laptops, tablets, and other devices in conference rooms and small huddle rooms. The SW-2X14KUSBC is intelligently designed to auto-switch between two devices. It supports video resolution up to 4K@60Hz 4:4:4 8-bit, 2K@60

KanexPro SW-2X14KUSBC 2-Input Collaboration System for Huddle Rooms Features:

  • A true 4K/60, 2x1 auto-switcher with HDMI 2.0 and USB-C inputs
  • Intelligent Automatic switching
  • Provides charging on USB-C port up to 60W perfect for MacBook & iPads
  • Controllable via front panel buttons & RS232C
  • Built-in EDID management
  • 4Kx2K@60Hz 4:4:4, HDR 10, Dolby Vision & HDCP 2.2.
  • Provides USB data (USB 3.0/2.0) and 4K video transmission on USB-C port.
  • Balanced analog audio for audio de-embedding.
  • Peripheral units (e.g. microphone and camera) can be connected by type-A USB (USB 3.0/2.0) ports and automatically switched along with HDMI and USB-C input as USB DEVICES for corresponding HOST.
  • Smart EDID management capable for various applications and customized setting.
  • Control via front panel buttons
  • Handles CEC & RS- 232 commands for display control such as, (ON, OFF, MUTE, VOL+, VOL -)
  • Low profile, perfect for lecterns, small to medium sized huddle rooms
  • International, locking power supply
  • Backed by KanexPro 3 year parts and labor warranty

Why not buy this KanexPro SW-2X14KUSBC 2-Input Collaboration System for Huddle Rooms today?

KanexPro SW-2X14KUSBC 2-Input Collaboration System for Huddle Rooms Specifications:

Video
Video Input (1) HDMI, (1) USB-C
Video Input Connector (1) Type-A female HDMI, (1) Type-C USB
HDMI Input Resolution Up to 4Kx2K@60Hz 4:4:4 8bit
USB-C Input Resolution Up to 4Kx2K@30Hz 4:4:4
Video Output (1) HDMI
Video Output Connector (1) Type-A female HDMI
HDMI Output Resolution Up to 4Kx2K@60Hz 4:4:4 8bit
HDMI Version 2.0
HDCP Version 2.2
USB Version 3.0
HDR 10 Supported
CEC Supported
HPD Supported
Audio
Audio Output (1) AUDIO OUT (Stereo balanced L/R)
Audio Output Connector (1) 5-pin terminal block
HDMI Audio Format LPCM 7.1 audio, Dolby Atmos®, Dolby® TrueHD, Dolby Digital® Plus,
DTS: XTM, and DTS-HD® Master AudioTM pass-through
Stereo balanced L/R audio Format PCM
Max Output Level 2.0Vrms ±0.5dB. 2V = 16dB headroom above -10dBV (316mV)
nominal consumer line level signal
THD+N < 0.05% (-80dB), 20Hz ~ 20KHz bandwidth, 1KHz sine at 0dBFS
 level (or max level)
SNR > 80dB, 20Hz ~ 20KHz bandwidth
Crosstalk Isolation > 70dB, 10KHz sine at 0dBFS level (or max level before clipping)
L-R Level Deviation < 0.3dB, 1KHz sine at 0dBFS level (or max level before
Frequency Response Deviation < ±0.5dB 20Hz ~ 20KHz
Output Load Capability 1KO and higher (supports 10x paralleled 10KO loads)
Stereo Channel Separation > 70dB@1KHz
Control Part
Control (1) EDID, (1) FW, (1) RS232, (1) HOST, (2) DEVICE
Control Connector (1) 4-pin DIP switch, (1) Micro-USB, (1) 3-pin terminal block,
(1) Type-B USB 3.0, (2) Type-A USB 3.0
General
HDMI 2.0 Cable Length 4K@60Hz 4:4:4 = 5m, 4K@60Hz 4:2:0 = 10m, 1080P = 15m
Bandwidth 18Gbps
Operation Temperature -10˚C ~ +55˚C
Storage Temperature -25˚C ~ +70˚C
Relative Humidity 10% ~ 90%
External Power Supply Input: AC 100~240V, 50/60Hz, Output: 24V DC 2.71A
Power Consumption 60W (Max)
Dimension (W*H*D) 6.6"x0.96"x3.74
Net Weight 0.54 lbs. (245g)

Why not buy this KanexPro SW-2X14KUSBC 2-Input Collaboration System for Huddle Rooms today?

SW-2X14KUSBCData Sheet

SW-2X14KUSBCUser Manual

Why not buy this KanexPro SW-2X14KUSBC 2-Input Collaboration System for Huddle Rooms today?

Warranty HDTV Supply includes a 3 Year Limited Warranty on all Kanex Pro products. The warranty states that (a) its products (the will perform substantially in accordance with the accompanying written materials for a period of 3 years from the date of receipt and (b) that the Product will be free from defects in materials & workmanship under normal use & service for a period of 3 years. In order to get a warranty replacement for a defective item, HDTV Supplys and Kanex Pros Support Team will verify the product is eligible for warranty. An RMA number will then be issued. Shipped replacements will be in like new conditions, tested and all components included. HDTV Supply also sells a 5 Year Extended U.S. Warranty for this Long-Runner HDMI 100M Extender. Please go to Extended Warranties or see the above Options to purchase it.
