WolfPack 4K 30 Hz HDBaseT 2.0 HDMI Extender Specs:

• HDMI Connector: HDMI Type A x 1
• HDMI Video Support 1080p @ 60Hz @ 48bits、3D、4K x 2K (YCbCr 4:2:0)
• HDMI Audio Support Up to 7.1 LPCM 192KHz / Dolby TrueHD / DTS-HD MA
• HDBaseT Connector RJ45 x 1
• HDBaseT Distance 100M
• RS-232 Connector DB9(F)/3.5mm STEREO PHONE JACK DB9(M)/3.5mm STEREO PHONE JACK
• RS-232 Baud Rate 115200 bps / full duplex
• IR Input/Output 3.5mm Phone Jack x 2
• IR Carrier Frequency / Angle/Distance 30~60KHz / T： 10 / R： 55 / 5M /Bi-directional
• Power Consumption 800mA 1200mA
• Power Adapter DC 5V 2A
• Temperature Operation: 0 to 55℃, Storage: -20 TO 85℃, Humidity: up to 95%

WolfPack 4K 30 Hz HDBaseT 2.0 HDMI Extender Contents:

• HDTVHE23UT HDMI Transmitter x 1 pcs
• HDTVHE23UR HDMI Receiver x 1 pcs
• IR Blaster Cable x 1 pcs
• IR Receiver Cable x 1 pcs
• DB9 (M)/3.5mm STEREO PHONE JACK x 1
• DB9 (F)/3.5mm STEREO PHONE JACK x 1
• Mounting Screw pack x 2 bags
• DC5V 2Amp Power Adapter x 2 pcs

HDBaseT Supports Full HD Uncompressed Video: HDBaseT delivers uncompressed HD video to a network of devices or as a point-to-point connection. Uncompressed content supports all video sources, including legacy products, accurately renders gaming graphics and features such as Electronic program guides, and does not degrade video quality or add latency. HDBaseT supports TV and PC video formats including standard, enhanced, high-definition and 3D video.

RS232: For RS232 control signal transmission, just connect two RS232 cables to both RS232 ports of HDMI over a single CAT6/6 Cable Extender Set, they work just like an RS232 extension cable.

Why not buy this 4K 30 Hz HDBaseT 2.0 HDMI Extender today?

User Manual

CAT6 Install Tips

Don't Use EZ45 Connectors

HDBaseT Dos & Don'ts

Operation Tips for HDbaseT Products with POC - Set Up Steps

Our WolfPack HDBaseT over CAT6 Extenders let set-top boxes, DVD players & other HDMI devices to be connected to HDMI displays that have an HDMI input that are >300 feet away from the source. These HDBaseT 2.0 & 1.4 products are the newest technology that supports HDMI 2.0, 1.4, 2D & 3D at >300 feet using only one CAT6 cable. By reducing the Ethernet cabling requirements from two to one, it allows you to easily tap into existing in-wall CAT6 wiring.

HDBaseT Video delivers full HD / 3D and 2K / 4K uncompressed video to a network of devices or to a single device (point-to-point ). Since the video is passed through the HDMI chipset, HDBaseT supports all key HDMI 1.4 and HDMI 2.0 features including EPG, CEC, EDID, and HDCP. HDBaseT is the only standard for delivering UltraHD 4K video up to 100m long.

HDBaseT audio passes through directly from the HDMI chipset and supports all standard formats including Dolby Digital, DTS, Dolby TrueHD and DTS HD-Master Audio.

These 4K 30 Hz HDBaseT Products Feature:

• Uncompressed video: The picture quality at 300 feet is the same as using a 3 foot HDMI cable.
• No more cable clutter: Fewer cables and less mess with its single cable connection
• Distance is no longer a concern: Runs over a 100m/328ft CAT6/7 cable and support for multi-hops (8 x 100m), HDBaseT provides point to point connectivity and full multimedia distribution with higher reliability, longer distance and lower cost
• Quality cable supports HD, 2D and 3D: HDBaseT utilizes a quality cable proven for transferring HD and new 3D formats
• Power over cable: Some of our HDBaseT products sends 100W of power simultaneously eliminating the need for a power outlet to be installed near the display
• Support for quality controls: HDBaseT supports various controls while ensuring reliability and low latency
• Low cost installations: Requires only one low cost LAN cable with standard RJ-45 connectors already installed in many homes

These HDBaseT products can support full 3D with resolutions up to 4Kx2K (4 times the 1080p), audio, IR remote and Ethernet sent over the same CAT6 cable. Many also feature 3DTV, deep color, lip sync and audio delay w/both the IR back-channel and RS-232 connection can be used to control the display from the remote location. We at HDTV Supply love HDBaseT products as we never get returns nor tech support calls so place your HDBaseT order today.

Why not buy one of our HDBaseT products today?

Q: What is HDBaseT 2.0?
A: HDBaseT 2.0 is the latest specification released by HDBaseT Alliance in August 2013. The new specification introduces HDBaseT HomePlay feature set that, based on the HDBaseT 5Play capabilities, will make it simpler and more cost-effective for consumers to turn their entire homes into multimedia entertainment centers. HomePlay features an elegant, affordable plug-and-play solution that will allow the average consumer to enjoy the same multimedia benefits of HDBaseT that the professionals have become accustomed to.

HDBaseT HomePlay defines the adaptations across all seven layers of the Generic communication OSI 7 model to allow the support of time-sensitive, high throughput video/audio and other time sensitive applications. While HDBaseT 1.0 addresses the Physical and Data Link layers only, HDBaseT 2.0 adds networking, switching and control point capabilities. HDBaseT 1.0 defined a point-to-point connectivity standard, HDBaseT 2.0 defines point-to-multi point connectivity, thereby providing multi-stream support.

Spec 2.0 also adds inherent support for USB 2.0, and other native interfaces which enable manufacturers to remove multiple interfaces and conversion components required for HDBaseT 1.0 products. The result is a smaller and a simpler-to- implement switch. HDBaseT 1.0 was defined to support the transmission of "video, audio, Ethernet, power and controls, what we refer to as the "5Play" feature set. Spec 2.0 establishes a specification that will allow HDBaseT HomePlay switches to control and distribute multimedia throughout consumers' homes.

HDBaseT 2.0 represents the culmination of more than two years of development work by both Pro-AV and CE manufacturers, and it offers significant benefits to the pro-AV companies such as native USB2.0 and additional features to improve performance margin including for 4K video and optimize the existing infrastructure and bandwidth.

Q: How is HDBaseT technology different than others?
A: Unlike other HD distribution technologies, HDBaseT is the only technology which enables CAT6/6/7 connectivity from 70 meters to 100 meters, depending upon the specific product, for uncompressed full HD multimedia content and up to 100 watts of charging power via a single cable. HDBaseT is optimized for video applications and can connect all HDBaseT enabled home entertainment devices. Also, HDBaseT technology has the capacity to deliver double the resolution available today to future 2K and 4K formats. Other existing solutions also require a specific cable and/or a new proprietary connector while HDBaseT utilizes the existing Ethernet infrastructure.
