This Dynacord V600-4-US 4-Channel 600W Power Amplifier this lightweight 4-channel amplifier is suitable for background music and announcements in small to medium-sized commercial installations. Its low energy consumption and flexible power-load allocation provide easy and trouble-free performance with a reduced cost of ownership.
The V600:4 boasts several notable features such as powerTANK, which acts as a reservoir of power, and the Variable Load Drive (VLD), which ensures that the powerTANK delivers consistent power to any channel, regardless of impedance. The built-in DSP handles input routing and offers HPF, LPF, and peak limiting per channel. The amplifier also features a PFC power supply and protection to ensure reliable and safe operation for years to come.
- Dynacord V600:4 Multichannel Power Amplifier for Commercial Installations
- IEC Power Cord
- 5-Pin Euroblock Remote Connector
- (2) 6-Pin Euroblock Audio Input Connector
- (2) 4-Pin Euroblock Speaker Output Connector
- (4) Rubber Feet
- (2) 19" Rackmount Bracket (Premounted)
- Limited 3-Year Manufacturer Warranty
Dynacord V600-4-US 4-Channel 600W Power Amplifier Features:
- 4-Channel Amplifier
- 600 W Total powerTANK Capacity
- dualCOOL Convection + Fan Cooling
- Drive at 4 or 8 Ohms & 70 or 100 V Loads
- ecoRAIL for Reduced Power Consumption
- Variable Load Drive to All Channels
- For Background Music and Announcements
- Euroblock Connectors
- Limited 3-Year Warranty
Why not buy this Dynacord V600-4-US 4-Channel 600W Power Amplifier from HDTV Supply today?
Dynacord V600-4-US 4-Channel 600W Power Amplifier Specifications:
- Amplifier:
- Number of Channels: 4
- Power Rating:
- 4 Ohms / 8 Ohms / 70 V / 100 V:
- (4) 150 W per Channel
- 4 Ohms / 70 V: (1) 500 W One Channel Driven (1 kHz)
- 8 Ohms / 100 V: 600 W One Channel Driven (1 kHz)
- Amplifier Class: Class-D
- Load Impedance / Voltage:
- 4 / 8 Ohms per Channel
- 70 V (33.2 Ohms)
- 100 V (36.2 Ohms)
- Performance:
- Protections: DC Fault, DC Offset, Output Limiter, Overcurrent, Overvoltage, Power Supply, RF, RMS, Short Circuit, Thermal, Ultrasonic, Undervoltage
- Frequency Response: 20 Hz to 20 kHz -3 dB
- Input Impedance: 20 Kilohms (Balanced)
- Max Gain:
- 30 dB (at 2 Ohms)
- 33 dB (at 4 Ohms)
- 39.2 dB (at 70 V)
- 42.2 dB (at 100 V)
- Max Input Level: 18 dBu
- SNR:
- > 98 dB (at 4 Ohms)
- > 100 dB (at 8 Ohms)
- > 101 dB (at 70 V)
- > 103 dB
- THD+N: < 0.1%
- Crosstalk:
- < -70 dB (4 Ohm)
- < -75 dB (8 Ohm)
- < -90 dB (70 V)
- < -95 dB (100 V)
- Signal Processing:
- DSP: Yes
- Crossover: Yes
- Limiting: Peak (per Channel)
- Connectivity:
- Analog Audio I/O:
- (2) Block 6-Pin Balanced Line Input
- (1) Proprietary 5-Pin Remote Input
- (2) Block 4-Pin Speaker Output
- Digital I/O: (1) RJ45 Amplink Input (I/O, Network)
- Mobile App Compatible: No *As of April, 2023: Check with manufacturer for the most up-to-date compatibility
- Power:
- AC Input Power: 100 to 240 VAC, 50 / 60 Hz
- AC Power Connector: IEC 15 A / NEMA 5-15
- Power Consumption:
- 115 W (1/8 Power)
- 20 W (Idle)
- 1 W (Standby)
- Physical:
- Display & Indicators:
- (4) Green LED (Signal)
- (4) Yellow LED (Limit)
- (4) Red LED (Fault)
- Rackmount Size: 1 RU
- Display & Indicators:
- Cooling:
- (1) Convection
- (1) Fan (Variable Speed)
- Operating Temperature: 23.0 to 113.0 °F / -5.0 to 45.0 °C
- Dimensions: 19.0 x 10.6 x 1.7 in / 48.3 x 26.9 x 4.3 cm
- Weight: 7.9 lb / 3.6 kg
