This Bolin Technology EG40F EDGE Series FAST HEVC Decoder
Mounting options:
- Base mount (included)
- Surface mount
- Din Rail mount
- Pole mount
- Tripod mount
- Tri-rack mount
- Single rack mount
- Vesa mount
Bolin Technology EG40F EDGE Series FAST HEVC Decoder Features:
- Support up to 4K60
- Hardware FPGA based codec, high-quality image with ultra low latency and low bandwidth
- Back compatible with standard HEVC codec but no Ultra-Low-Latency
- HDMI 2.0 + 12G-SDI video output
- True Dual-Output
- All video with audio embedded
- Support PTZ control
- Audio intercom with frontend device
- On-screen character generator
- Firmware upgrade via IP
- POE+ and 12VDC power input
Why not buy this Bolin Technology EG40F EDGE Series FAST HEVC Decoder today?
Bolin Technology EG40F EDGE Series FAST HEVC Decoder Specifications:
- Encoder/Decoder: Decoder only
- Decoder (Video Output): HDMI & SDI
- Video Codec: AVC-H.264 / HEVC-H.265 selectable
- Codec Platform: Hardware FPGA FAST HEVC codec
- Video Resolutions: 3840 x 2160P @60/59.94/50/30/29.97/25/24/23.98 1920 x 1080P @60/59.94/50/30/29.97/25/24/23.98 1920 x 1080i @60/59.94/50 1280 x 720P @60/59.94/50/30/29.97/25
- Color Space(HDMI): 4K60: RGB 8bit, YUV444 8bit, YUV422 12bit, YUV420 8bit/10bit 4K30 & below: RGB 8bit/10bit, YUV444 8bit/10bit, YUV422 12bit
- Audio Formats: 3.5mm Jack, analog audio, stereo (unbalanced); Line in/out - audio intercom, Line out - HDMI audio output
- Video Streaming: 1 stream
- Control Protocol: Visca serial control (RS422), Visca over IP
- Latency (Results may vary depending on network configuration and management settings): A: <2 frame (e.g. 2160p60 latency is < 30 ms between encoder and decoder)
- B: <1.5 frame (e.g. 1080p60 latency is < 15 ms between encoder and decoder)
- Bandwidth (Results may vary depending on network configuration and management settings): A: 4kp60 4:2:2/12bit; 20-50Mbps
- B: 1080p60 4:2:2/12bit; 10-25Mbps
- Ecosystem Friendly: A: AVC-H.264/HEVC-H.265 Open Platform, compatible with standard AVC/HEVC software/hardware decoder
- B: Video codec is compatible with decoding standard AVC/HEVC, H.264/265 to output video without having low latency; Pair up with Fast HEVC encoder to decode output extremely low latency video.
Why not buy this Bolin Technology EG40F EDGE Series FAST HEVC Decoder today?
Bolin Technology EG40F Specifications
