WolfPack 16x16 SDI and DVB-ASI Matrix Switcher
WolfPack 16x16 SDI and DVB-ASI Matrix Switcher is a professional matrix switcher of high-performance embedded intelligent control. Our SDI is compatible with ASI which is used widely in broadcasting program transmission. It provides a stable and reliable high-definition audio and video signal transmission switching hub for the system.
It is widely applied in digital video multi-screen display systems, radio and television systems, multimedia video conference, large screen display systems, high definition television teaching, visual command and control centers, medical teaching, etc
WolfPack 16x16 SDI and DVB-ASI Matrix Switcher
- Compatible with SMPTE259M/292M/344M/424M , DVB-ASI
- Support clock recovery
- Built in self-adaptable equalize
- Power off self-protection
- High-quality, high-volume production, high compatibility and stability, and highly cost effective;
- Front panel LED shows switching status
- Switching mode: RS-232, panel buttons, IP
- Rack mount design for easy installation
- 3-Year Warranty
Why not buy this WolfPack 16x16 SDI and DVB-ASI Matrix Switcher today?
WolfPack 16x16 SDI and DVB-ASI Matrix Switcher
Category | SDI Matrix Switcher |
SDI Video | |
Application standard | SMPTE424M,SMPTE295M,SMPTE292M,ITU-R BT.601,ITU-R BT.1120 |
Video format | 270Mbps SDI,1.485Gbps HD-SDI & 2.97Gbps 3G-SDI |
Data frequency | 19Mbps to 2.97Gbps |
Range | 0.8Vp-p±10% |
Rise/fall time | <270ps |
DC excursion | 0v±0.5v |
Overshoot | <10% |
Shift | <540ps±10% |
Min/max electricity frequency | 0.5V to 1.0Vp-p |
Max transmission range | 3G: 120m. HD: 200m SD:400m(use 75-5,128 professional video line,or 75-5 closed circuit television line, far transmit distance and low cost |
Input impedance | 75Ω |
Return loss | <-15dB, DC@1MHz to 1.5 GHz |
DC compensation | Max ±5mV |
Output impedance | 75Ω |
control interface | |
Serial control interface | RS-232, 9-pin female D-type interface |
Baud rate and protocol | Baud rate: 9600, data bit:8, stop bit: 1, no parity |
IP | RJ45 port |
Working Environment | |
Power supply | 100VAC~240VAC, 50/60 Hz, international adaptive power |
Temperature | Storage and operating temperature: -40˚:~ +70˚:C |
Humidity | Storage and operating humidity: 10% ~ 90% |
MTBF | 60,000 hours |
